LTCXSM series double shaft rod cylinder

Location:	China
Business Type:	Manufacturer, Exporter
Brands:	Own Brand, OEM,
Certificate:	ISO9001, CE
Model:
Terms of payment and delivery:	FOB NINGBO
Minimum order quantity:	1 PCS
Price:	Consultation
Delivery time:	15 days after confirmation of artwork and deposit
Payment method:	TT 30% deposit，balance against BL copy

Quote Now

Specification

Bore(mm)	10	15	20	25	32
Working Medium	Clean Air
Acting Type	Double Acting
Stroke	0-100mm	0-200mm
Working Pressure	0.1~1.0Mpa
Ensured Pressure Resistance	1.5Mpa
Operating Temperature	-10~70℃(No freezing)
Operating Speed Range	30-500mm/s
Adjust Stroke	-3~0
Cushion Type	Rubber Cushion
Port Size	M5*0.8				G1/8

A Double Shaft Rod Cylinder is a type of hydraulic cylinder that features two opposing ends and a single piston. These two ends do reciprocal work. Both of them move with equal force, stroke length, and speed. These types of cylinders, which feature push and pull force from both ends. They are also available in various bore sizes. To ensure their longevity, the cylinders are designed for high-speed applications.
